Pin Assignment Signal
PIN Description PIN Description
1 Red 9 +5V
2 Green 10 N.C.
3 Blue 11 N.C.
4 N.C. 12 DDC_SDA
5 GND 13 HSYNC
6 Red_GND 14 VSYNC.
7 Green_GND 15 DDC_SCL
8 Blue_GND
Technical Information
Signal
Digital Video Input Connector : DVI – D (option)
1 TX1- TX0-
2 TX1+ 18
Shield (TX2 / TX4)
NC 12 20
5 13 21
6 22
23
8 Hot plug detect
TX2-
TX2+
9 17
10
TX0+
11 Shield (TX0 / TX5) 3 Shield (TX1 / TX3) 19
4 NC NC
NC NC NC
+5V power DDC-Serial Clock 14 Shield (TXC)
7 15 Ground (+5V) TXC+
NC
DDC-Serial Data
16 TXC- 24
