English Projector Overview
Projector Outlook
Front / upper side
Rear side
# Description # Description
1 Zoom lens 6 Power button
2 Tilt adjusting wheel 7 Remote control
3 Remote control receivers 8 Ventilation (inlet)
4 Focus ring 9 Ventilation (outlet)
5 Zoom lever
7
6
3
4
3
8
5
8
9
1
2
VGA IN S-VIDEO VIDEO
X1163/X113
VGA IN S-VIDEO VIDEO RS232 VGA OUT AUDIO IN
P1163
VGA IN S-VIDEO VIDEO RS232 VGA OUT AUDIO IN
X1263
8
4 6 5 3 2 1
10
7
9
