Acer V176L - Manual (Page 4)

LCD Monitor Quick Setup Guide
E
n
g
li
sh
SPECIFICATION
Find manuals and other documents for your Acer product on the official Acer support website.
LCD Panel Driving system TFT Color LCD
Size 17” (43 cm)
Pixel pitch 0.264 mm (H) x 0.264 mm (V)
Brightness 250 cd/m 2 (Typical)
Contrast 100000000:1 Max (ACM)
Viewable angle 170° (H) 160° (V) (CR=10)
Response time 5 ms
Panel Type TN
Video R,G, B Analog Interface
H-Frequency 30 kHz - 80 kHz
V-Frequency 55 - 75 Hz
Display Colors 16.7M Colors
Dot Clock 135 MHz
Max. Resolution 1280 x 1024 @ 75 Hz
Plug & Play VESA DDCCI/DDC2B
Power consumption (at 200 nits) On Mode 13W (typ.)
Sleep Mode 0.45W (typ.)
Off Mode 0.35W (typ.)
Input Connector D-Sub
DVI-D 24 pin (Only Dual-Input Model)
Input Video Signal Analog: 0.7Vp-p (standard), 75 OHM, Positive
Digital signal (Only Dual-Input Model)
Speakers 1W x 2 (Only Audio-Input Model)(Optional)
Maximum Screen Size Horizontal: 337.9 mm
Vertical: 270.3 mm
Power Source 100-240V, 50/60 Hz
Environmental Considerations Operating Temp: 5° to 35°C
Storage Temp: -20° to 60°C
Operating Humidity: 10% to 85%
Dimensions 369 (W) x 394.5 (H) x 191 (D) mm
Weight (N. W.) 2.56 kg Unit (net)
Mechanism spec Tilt: -5° to +25°
Swivel: No
Height adjustment: No
Pivot: No
Detachable foot stand: Yes (by Release button)
External Controls: Switch / Buttons Power Button
Left(
W) /Right(X)
MENU/ENTER
Auto/ Exit
E(Empowering) Key
Functions Contrast
Brightness
Focus
Clock
H. Position
V. Position
(Warm) Color
(Cool) Color
RGB Color temperature
Language
OSD position. timeout Auto configuration (only
Analog input model)
ACM On/Off
Input signal Selection (only
Dual input model)
DDCCI On/Off
Display information
Reset
Exit
* All specifications are subject to change without notice.
Regulatory Compliance
ME61
UA.TR.002
