How to get a preferred image size by adjusting
distance and zoom
The table below shows how to achieve a desired image size by adjusting either
the position or the zoom ring.
•
X1160/P series Example: to obtain an image size of 50" set the projector at
2m distance from the screen.
•
X1160Z/ZC/PZ/PZC, X1260/Z/ZC/P/PZ/PZC/K/KC series Example: to obtain an
image size of 50" set the projector at a distance 2 m and 2.2 m from the
screen and adjust the zoom level accordingly.
Desired Distance
Height
Form base to
top of image
2 m
2.2 m
50"
Desired
image size
A
C
D
B
