English Projector Overview
Projector Outlook
Front / upper side
Rear side
# Description # Description
1 Projection lens 4 Power button
2 Tilt adjusting wheel 5 Control panel
3 Focus ring 6 Remote control receiver
# Description # Description
1 Remote control receiver 5 HDMI connector
2 MicroSD Card Slot 6 AV Input Connector
3 USB connector 7 DC Input
4
Universal connector for VGA/ Audio
in/ Audio out connector
5
2
1
3
4
6
USB
HDMI
UNIVERSAL I/O
AV IN DC IN
micro
2
5
1
4 6 7
3
