18
GB
Installation
! Before placing your new appliance into operation please read
these operating instructions carefully. They contain important
information for safe use, for installation and for care of the
appliance.
!
Please keep these operating instructions for future reference.
Pass them on to possible new owners of the appliance.
Positioning and connection
Positioning
1. Place the appliance in a well-ventilated humidity-free room.
2. Do not obstruct the rear fan grills. The compressor and
condenser give off heat and require good ventilation to
operate correctly and save energy.
3. Leave a space of at least 10 cm between the top part of the
appliance and any furniture above it, and at least 5 cm
between the sides and any furniture/side walls.
4. Ensure the appliance is away from any sources of heat (direct
sunlight, electric stove, etc.).
5. In order to maintain the correct distance between the
appliance and the wall behind it, fit the spacers supplied in
the installation kit, following the instructions provided.
Levelling
1. Install the appliance on a level and rigid floor.
2. If the floor is not perfectly horizontal, adjust the refrigerator by
tightening or loosening the front feet.
Electrical connections
After the appliance has been transported, carefully place it
vertically and wait at least 3 hours before connecting it to the
electricity mains. Before inserting the plug into the electrical
socket ensure the following:
• The appliance is earthed and the plug is compliant with the law.
• The socket can withstand the maximum power of the
appliance, which is indicated on the data plate located on the
bottom left side of the fridge (e.g. 150 W).
• The voltage must be in the range between the values
indicated on the data plate located on the bottom left side
(e.g. 220-240V).
• The socket is compatible with the plug of the appliance. If the
socket is incompatible with the plug, ask an authorised
technician to replace it (
see Assistance). Do not use
extension cords or multiple sockets.
! Once the appliance has been installed, the power supply cable
and the electrical socket must be easily accessible.
!
The cable must not be bent or compressed.
! The cable must be checked regularly and replaced by
authorised technicians only (see Assistance).
!
The manufacturer declines any liability should these safety The manufacturer declines any liability should these safety The manufacturer declines any liability should these safety The manufacturer declines any liability should these safety The manufacturer declines any liability should these safety
measures not be observed. measures not be observed. measures not be observed. measures not be observed. measures not be observed.
Accessories
Refrigerator compartment
SHELVES: with or without grill.
Due to the special guides the shelves are removable and the
height is adjustable, allowing easy storage of large containers
and food. Height can be adjusted without complete removal of
the shelf.
FRESH BOX
*
: for fresh meat and fish. Due to the
compartment’s low temperature (the coldest in the refrigerator)
and to the clear door that provides protection against oxidation
and blackening, food can be stored for even up to one week. It
can also be used for “cold meals.”
ODOUR FILTER
*
: Some models are fitted with a new odour filter
with active carbons, which ensures better air quality inside the
refrigerator.
The filter is located on the bottom left side, inside the FRUIT and
VEGETABLE compartment.
TEMPERATURE Indicator light
*
: to identify the coldest area in
the refrigerator.
1. Check that OK appears clearly on the indicator light ( see
diagram).
2. If the word “OK” does not appear it means that the temperature
is too high: adjust the REFRIGERATOR OPERATION knob to a
higher position (colder) and wait approximately 10 hours until
the temperature has been stabilised.
3. Check the indicator light again: if necessary, readjust it
following the initial process. If large quantities of food have
been added or if the refrigerator door has been opened
frequently, it is normal for the indicator not to show OK. Wait at
least 10 hours before adjusting the REFRIGERATOR
OPERATION knob to a higher setting.
Freezer compartment
ICE CARE tray
The fact that they are situated on the top part of the freezer
drawers ensures greater cleanliness: the ice no longer comes
into contact with the food placed inside the freezer compartment;
furthermore, the dripping of the water during filling is avoided (a
lid to cover up the hole after filling with water is also provided).
1. Pull out the tray by pushing it up.
Check that the tray is ompletely empty and fill it with water
through the opening provided.
2. Take care not to exceed the level indicated (MAX WATER
LEVEL). Excess water prevents the ice cubes from dispensing
(if this happens, wait for the ice to melt and empty the tray).
* Available only on certain models.
