Factory Default Settings:
The 40697 will retain input/output settings when powered off by the remote control or the switch’s
front face power button.
Unplugging the supplied power adapter from the switch, will automatically restore the factory
default setting. The default factory setting routes Input 1 to Output 1 and Output 2
simultaneously.
Specifications:
Power Requirement: DC 12V 500mA (Using the Supplied AC Adapter)
Power consumption: 6 Watts
Sampling frequency: 44.1K Hz
Optical Output Level: 6uW Min.
Video Component Input Impedance: 75Ω
Video Bandwidth: -3dB@300MHz
Dimensions (HWD): 67x 345 x 175 mm
Weight: 1,825 g
