154.113UK User Manual
:12 channels mode
CH No. DMX value Function
CH1
000~010 CLOSE(No.1 OUTPUT SOCKET)
011~255 OPEN(No.1 OUTPUT SOCKET)
CH2
000~010 CLOSE(No.2 OUTPUT SOCKET)
011~255 OPEN(No.2 OUTPUT SOCKET)
CH3
000~010 CLOSE(No.3 OUTPUT SOCKET)
011~255 OPEN(No.3 OUTPUT SOCKET)
CH4
000~010 CLOSE(No.4 OUTPUT SOCKET)
011~255 OPEN(No.4 OUTPUT SOCKET)
CH5
000~010 CLOSE(No.5 OUTPUT SOCKET)
011~255 OPEN(No.5 OUTPUT SOCKET)
CH6
000~010 CLOSE(No.6 OUTPUT SOCKET)
011~255 OPEN(No.6 OUTPUT SOCKET)
CH7
000~010 CLOSE(No.7 OUTPUT SOCKET)
011~255 OPEN(No.7 OUTPUT SOCKET)
CH8
000~010 CLOSE(No.8 OUTPUT SOCKET)
011~255 OPEN(No.8 OUTPUT SOCKET)
CH9
000~010 CLOSE(No.9 OUTPUT SOCKET)
011~255 OPEN(No.9 OUTPUT SOCKET)
CH10
000~010 CLOSE(No.10 OUTPUT SOCKET)
011~255 OPEN(No.10 OUTPUT SOCKET)
CH11
000~010 CLOSE(No.11 OUTPUT SOCKET)
011~255 OPEN(No.11 OUTPUT SOCKET)
CH12
000~010 CLOSE(No.12 OUTPUT SOCKET)
011~255 OPEN(No.12 OUTPUT SOCKET)
Specifications
Power supply 230Vac, 50Hz
Maximum current input 30A
Maximum current per channel 10A
IEC outputs 12
Dimensions 440 x 205 x 88mm
Weight 3.8kg
