Errors and omissions excepted.

Set-up Examples

Install directly to TV

Install though set-top box

After the mounting and installation is finished, adjust the aerial to the best position to receive the signal.
Keep the aerial away from interference sources such as air conditioners, hair dryers, microwaves etc.
Ideally the aerial should be installed as high as possible.

Specification
Power supply

230Vac, 50Hz (3W) / 12Vdc, 50mA

Frequency range: UHF 470MHz – 862MHz
Frequency range: VHF 40MHz – 230MHz
Gain

20dB

Impedance

75Ω

Weight

1.5kg
