Air Suspension AS-2194 REV 2 User Manual
Page 6
6
AS-
2194
ARNOTT REMANUFACTURED REAR AIR STRUT
FOR
1999-2006
MERCEDES-BENZ S-CLASS (W
220
CHASSIS)
W/O ABC
AS-2194
REV 2
02/06/2014
15.
LOOSEN THE LOWER CONTROL BOLT SLIGHTLY (THIS WILL ALLOW THE LOWER CONTROL ARM TO SWING
DOWN. (FIGURE K)
16.
REMOVE SHOCK ASSEMBLY FROM CAR. (FIGURE L)
17.
REMOVAL COMPLETE.
FIGURE K
FIGURE L
AIR STRUT INSTALLATION
1.
INSTALLATION IS IN REVERSE ORDER OF AIR STRUT REMOVAL.
Tighten all nuts and bolts to manufacturer's specifications during the installation process.
