3 REV 2 11/14/2013 C-2608
C-2608
ARNOTT REAR COIL SPRING CONVERSION KIT
FOR 1997-2002
FORD EXPEDITION/LINCOLN NAVIGATOR
8. CAREFULLY REMOVE AIR SPRING FROM THE VEHICLE.
9. UNPLUG THE AIR SPRING SOLENOID POWER SUPPLY, AND REMOVE THE AIR HOSE BY PUSHING
DOWN ON THE ORANGE QUICK RELEASE RING WHILE PULLING OUTWARD ON THE HOSE.
10. REMOVE THE AIR SPRING SOLENOID.
11. SEAL OFF HOSE TO PREVENT DIRT OR GREASE FROM ENTERING SYSTEM.
12. REMOVE BOTH REAR SHOCKS TO ALLOW AXLE TO HANG FREE UNSUPPORTED. THIS
WILL GIVE YOU EXTRA CLEARANCE FOR THE COIL SPRING.
INSTALLATION
1. INSTALL THE COIL SPRINGS ONTO THE REAR AXLE.
2. USING A FLOOR JACK, RAISE THE REAR AXLE.
3. INSTALL THE REAR SHOCK ABSORBERS.
4. REMOVE THE REAR AXLE SUPPORT.
5. REPLACE TIRE AND WHEEL ASSEMBLY.
6. REMOVE ALL SAFETY STANDS AND LOWER VEHICLE.
DISARMING THE AIR SUSPENSION SYSTEM
LOCATE THE VEHICLES AIR SUSPENSION CONTROL MODULE. UNPLUG THE WIRING HARNESS FROM THE CONTROL
MODULE TO ELIMINATE ANY DASH WARNING LIGHTS.
Tighten all nuts and bolts to manufacturer's specifications during the installation process.
Tie the wires and air hose back away from any hot or moving parts. Do not cut the wires. Leave the system
whole in case you ever want to reinstall air suspension on the vehicle. NOTE:
