Air Suspension P-2291 REV 1 User Manual
Page 4
4
REV 1
01/09/2013
P-2291
P-
2291
WABCO OES AIR SUSPENSION COMPRESSOR
FOR
2004-2010
JAGUAR XJ
8
5.
REMOVE THE THREE (3) NUTS SECURING THE COMPRESSOR TO THE MOUNTING BRACKET AND REMOVE
COMPRESSOR (FIGURE D).
6.
REMOVAL COMPLETE.
AIR SUSPENSION COMPRESSOR INSTALLATION
1.
INSTALLATION IS IN REVERSE ORDER OF AIR SUSPENSION COMPRESSOR REMOVAL.
Tighten all nuts and bolts to manufacturer's specifications during the installation process.
Do not remove the air fitting from the air suspension compressor. Doing so may cause damage and/or void warranty.
Remove the white shipping pin from the new air fitting and insert the air line until fully seated.
