Air Suspension A-2647 REV 1 User Manual
Page 3
3
A-
2647
ARNOTT REAR AIR SPRING
FOR
2007-2012
LINCOLN NAVIGATOR/FORD EXPEDITION
REV 1
12/11/2013
A-2647
2.
TURN THE ASSEMBLY UPSIDE DOWN AND USING A FLAT HEAD SCREWDRIVER DEPRESS THE SECURING
TABS TO DISLODGE THE PISTON FROM ITS POSITION.
3.
REMOVE THE SHOCK FROM THE AIR SPRING ASSEMBLY.
4.
PULL THE RETAINING PINS HOLDING THE UPPER MOUNT TO THE AIR SPRING TOP AND PRY THE MOUNT
OFF (IF A NEW MOUNT WAS PURCHASED,YOU MAY DISREGARD THIS STEP).
AIR SPRING INSTALLATION
1.
CLEAN THE REUSED PARTS AND APPLY THE NEW O-RINGS WITH LUBRICANT.
2.
INSTALL THE NEW AIR SPRING ONTO THE SHOCK ABSORBER.
3.
INSTALL EITHER THE REUSED OR NEW TOP MOUNT ONTO THE AIR SPRING AND FIRMLY SEAT THEM
TOGETHER.
4.
SECURE THE ROD END NUT AND THE RETAINER PINS INTO PLACE ON THE UPPER MOUNT.
AIR STRUT INSTALLATION
1.
INSTALLATION IS IN REVERSE ORDER OF AIR STRUT REMOVAL.
Tighten all nuts and bolts to manufacturer's specifications during the installation process.
