ASUS KGPE-D16 4-17
v02.61 (C)Copyright 1985-2010, American Megatrends, Inc.
BIOS SETUP UTILITY
Advanced
Advanced Chipset Settings
NorthBridge Configuration
SouthBridge Configuration
SR5690 Configuration
←→ Select Screen
↑↓ Select Item
Enter Go to Sub Screen
F1 General Help
F10 Save and Exit
ESC Exit
4.4.2 Chipset Configuration
The Chipset configuration menu allows you to change advanced chipset settings.
Select an item then press to display the submenu.
Options for NB
NorthBridge Configuration
v02.61 (C)Copyright 1985-2010, American Megatrends, Inc.
BIOS SETUP UTILITY
Advanced
NorthBrideg Chipset Configuration
Memory Configuration
ECC Configuration
DRAM Timing Configuration
Memroy Timing Parameters [CPU Node 1]
Memory CLK :533 MHz, N/A
CAS Latency(Tcl) :7 CLK , N/A
RAS/CAS Delay(Trcd) :7 CLK , N/A
Row Precharge Time(Trp):7 CLK , N/A
Min Active RAS(Tras) :20 CLK, N/A
RAS/RAS Delay(Trrd) :4 CLK, N/A
Row Cycle (Trc) :27 CLK, N/A
Read to Precharge(Trtp):4 CLK, N/A
Write Recover Time(Twr):8 CLK, N/A
←→ Select Screen
↑↓ Select Item
Enter Go to Sub Screen
F1 General Help
F10 Save and Exit
ESC Exit
