Hotpoint Ariston Combinado EBL 20311 V - Manual (Page 25)

GB
25
• Do not re-freeze food that is defrosting or that has already been
defrosted. These foods must be cooked and eaten (within 24
hours).
• Fresh food that needs to be frozen must not come into contact
with food that has already been defrosted. Fresh food must be
stored in the top FREEZER and STORAGE compartment where
the temperature drops below -18°C and guarantees rapid
freezing.
• To freeze fresh food in the best and safest way possible, activate
the SUPER FREEZE function 24 hours before placing the food in
the freezer. After placing the food inside, activate the SUPER
FREEZE function again; it will be deactivated automatically after 24
hours;
• Do not place glass bottles which contain liquids, and which are
corked or hermetically sealed in the freezer because they could
break.
• The maximum quantity of food that may be frozen daily is
indicated on the plate containing the technical properties located
on the bottom left side of the refrigerator compartment (for
example: Kg/24h: 4).
• In order to obtain a greater amount of space in the freezer
compartment, you may remove the bins (except the lowest bin
and the special COOL CARE ZONE bin, which has an
adjustable temperature) and place the food directly onto the
evaporator plates.
! If the room temperature drops below 14°C for an extended period
of time, the ideal temperature will not be reached in the freezer
compartment and food preservation will be reduced.
!
Do not open the door during freezing.
! If there is a power cut or malfunction, do not open the freezer
door. This will help maintain the temperature inside the freezer,
ensuring that foods are conserved for at least 9 -14 hours.
Easy Ice
*
The double tub was designed to optimise space in the freezer
compartment and to ensure that ice is always readily available. The
trays can be stacked or filled and used separately.
Furthermore, the special fastening system makes Easy Ice an
extremely flexible solution, as it can be positioned in the right or left
part of the top drawers.
Maintenance and care
Switching the appliance off
During cleaning and maintenance it is necessary to disconnect the
appliance from the electricity supply:
1. set the FREEZER OPERATION knob on
2. pull the plug out of the socket
Cleaning the appliance
• The external and internal parts, as well as the rubber seals may
be cleaned using a sponge that has been soaked in lukewarm
water and bicarbonate of soda or neutral soap. Do not use
solvents, abrasive products, bleach or ammonia.
• The removable accessories may be soaked in warm water and
soap or dishwashing liquid. Rinse and dry them carefully.
• The back of the appliance may collect dust which can be
removed by delicately using the hose of a vacuum cleaner set
on medium power. The appliance must be switched off and the
plug must be pulled out before cleaning the appliance.
Avoiding mould and unpleasant odours
• The appliance is manufactured with hygienic materials which are
odour free. In order to maintain an odour free refrigerator and to
prevent the formation of stains, food must always be covered or
sealed properly.
• If you want to switch the appliance off for an extended period of
time, clean the inside and leave the doors open.
Defrosting the appliance
! Follow the instructions below.
Do not speed up the defrosting process by using any devices or
tools other than the scraper provided, you may damage the
refrigeration circuit.
Defrosting the refrigerator compartment
The refrigerator has an automatic defrosting function: water is
ducted to the back of the appliance by a special discharge outlet
(
see diagram) where the heat produced by the compressor
causes it to evaporate. It is necessary to clean the discharge hole
regularly so that the water can flow out easily.
Defrosting the freezer compartment
If the frost layer is greater than 5 mm, it is necessary to defrost
manually:
1. Set the TEMPERATURE ADJUSTMENT knob to the position
O F F
2. Wrap frozen foods in newspaper and place them in another
freezer or in a cool place.
3. Leave the door open until the frost has melted completely. This
can be made easier by placing containers with lukewarm water
in the freezer compartment.
4. Clean and dry the freezer compartment carefully before
switching the appliance on again.
5. Certain appliances are fitted with the DRAIN SYSTEM to lead the
water outside: let the water flow into a container ( see diagram).
* Varies by number and/or position, available only on certain
models.
