ASUS RS700-E7/RS4-C 1-3
1.3 System specifications
The ASUS RS700-E7/RS4-C feature the ASUS Z9PP-D24 server board. The
server supports Intel ® Socket-R LGA2011 Xeon ® series processors with EM64T
technology, plus other latest technologies through the chipsets onboard.
(continued on the next page)
Model Name RS700-E7/RS4-C
Processor / System Bus
2 x Socket-R (LGA2011)
8/6/4 Core Intel
® Xeon E5-2600 Series (Up to TDP=115W)
QPI 6.4 / 7.2 / 8.0 GT/s
Core Logic
Intel ® C602 chipset
ASUS Features
Smart Fan √
ASWM
Enterprise
√
Memory
Total Slots 24 (4-channel per CPU, 12 DIMMs per CPU)
Capacity
Maximum up to 192GB (RDIMM)
Maximum up to 128GB (UDIMM)
Maximum up to 192GB (LRDIMM)
Memory Type
DDR3 1600 / 1333 / 1066 / 800 Reg DIMM
DDR3 1333/ 1066 Unbuffered DIMM with ECC
DDR3 1333/ 1066 LRDIMM
Memory Size
2GB, 4GB, and 8GB (RDIMM)
2GB, 4GB, and 8GB (UDIMM)
8GB (LRDIMM)
Expansion Slots
Total PCI/PCI-X/
PCI-E Slots
2+1
Slot Type 2 x PCI-E G3 x16 (x16 Link) ( Full-height/Half-lengh)
Additional Slot 1 x PIKE slot for storage enhancement
Storage
SATA Controller
Intel ® C602 chipset:
2x SATA 3Gb/s ports
1x ISATA1 port (2 x SATA 3 Gb/s+2 x SATA 6Gb/s)
Intel RSTe (For Windows only)
- Supports S/W RAID 0,1,10 & 5)
LSI MegaRAID (for Linux / Windows):
- Supports software RAID 0, 1 & 10\
1x ISAS1 port (4 x SATA 3Gb/s)
Intel RSTe (For Windows only)
- Supports S/W RAID 0,1,10 & 5)
SAS Controller
Optional:
ASUS PIKE 2008 8-port SAS2 6G RAID card
ASUS PIKE 2008/IMR 8-port SAS2 6G RAID card
ASUS PIKE 2108 8-port SAS2 6G H/W RAID card
HDD Bays
I = internal
A or S will be
hot-swappable
4 x Hot-swap 3.5” SATA/SAS HDD Bays
Networking LAN 1 x Dual-port Intel ® I350-AM2 + 1 x Mgmt LAN
Graphic VGA Aspeed AST2300 + 16MB VRAM
