Page 37
ASUS P7F-C Series
2-19
2.5.4
PCI Express x16 slots (x8 link)
The onboard PCI Express x16 slots provide x8 link to CPU. These slots support
VGA cards and various server class high performance add-on cards.
2.5.5
PCI slots
The PCI slot supports cards such as a LAN card, USB card, and other cards that
comply with PCI 2.3 specifications.
PCI slot
PCI slot
PCI slot
PCI Express x16 slot
(x8 link)
PCI Express x16 slot
(x8 link)
PCI slot
