Perangkat keras
Panel depan
Panel depan dilengkapi indikator LED yang akan menampilkan status switch
secara real-time.
Indikator LED
LED
Warna
Status
Keterangan
DAYA
Hijau
MENYALA
Switch dalam kondisi AKTIF.
MATI
Switch dalam kondisi NONAKTIF.
Status
Hijau
MENYALA
Link yang valid telah tersedia.
Berkedip
Menerima atau mengirim paket
data.
Panel belakang
Panel belakang dilengkapi port Ethernet dan port input DC IN.
DC 12V
