2-16 Chapter 2: Getting started
[100:133] The CPU bus speed to DRAM speed ratio is set to 100:133.
[100:100] The CPU bus speed to DRAM speed ratio is set to 100:100.
2.5.7 Memory Frequency [Auto] (B85-PLUS)
DRAM Frequency [Auto] (B85-PRO)
Allows you to set the memory operating frequency. The configuration options vary with the
previous item settings.
Selecting a very high memory frequency may cause the system to become unstable! If this
happens, revert to the default setting.
2.5.8 CPU Graphics Max. Ratio [Auto] (B85-PLUS)
Max. CPU Graphics Ratio [Auto] (B85-PRO)
[Auto] The CPU Graphics Max. ratio is set to its optimized setting depending on
the system loading.
[Manaul] Use the <+> or <-> keys to adjust the optimal CPU Graphics Max. ratio.
The value may vary depending on the system loading.
2.5.9 GPU Boost [As is]
GPU Boost accelerates the integrated GPU for extreme graphics performance. Configuration
options: [As Is] [Enabled].
2.5.10 EPU Power Saving Mode [Disabled]
Allows you to enable or disable the EPU power saving function. Configuration options:
[Disabled] [Enabled]
2.5.11 DRAM Timing Control
The subitems in this menu allow you to set the DRAM timing control features. Use the <+>
and <-> keys to adjust the value. To restore the default setting, type [auto] using the keyboard
and press the key.
Changing the values in this menu may cause the system to become unstable! If this
happens, revert to the default settings.
Primary Timings
DRAM CAS# Latency [Auto]
Configuration options: [Auto] [1 DRAM Clock] – [31 DRAM Clock]
DRAM RAS# to CAS# Delay [Auto]
Configuration options: [Auto] [1 DRAM Clock] – [31 DRAM Clock]
DRAM RAS# PRE Time [Auto]
Configuration options: [Auto] [1 DRAM Clock] – [31 DRAM Clock]
