Chapter 1: Knowing the Parts 1-8
1
Left Side
Refer to the diagram below to identify the components on this side of the
Eee PC.
Power (DC) Input
The supplied power adapter converts AC power to DC power
for use with this jack. Power supplied through this jack supplies
power to the Eee PC and charges the internal battery pack. To
prevent damage to the Eee PC and battery pack, always use the
supplied power adapter.
THE ADAPTER MAY BECOME WARM TO HOT WHEN IN USE. BE
SURE NOT TO COVER THE ADAPTER AND KEEP IT AWAY FROM
YOUR BODY.
15 pin D-Sub Display (Monitor) Output
HDMI HDMI output
Remember to detach the HDMI cable when using your EeePC as
the major video and audio playback device.
USB Port (2.0/1.1)
USB Charge+
Allows you to charge your mobile phones or digital audio players
while your Eee PC is sleeping, hibernating or shut down. Launch
the USB Charge+ application from Eee Docking tool bar and
configure related settings.
2
3
4
1 2 4 6 3 5
