Page 27: 27 getting started
27
Getting Started
3
Microsoft Windows Keys
There are two special Windows keys on the keyboard as described below.
The key with the Windows Logo activates the Start menu located at the bottom left of the
Windows desktop.
The other key, that looks like a Windows menu with a small cursor, activates the properties
menu and is equivalent to pressing the right mouse button on a Windows object.
NOTE: The arrow symbols are illustrated here for your reference. They are not labeled
on the keyboard as shown here.
Keyboard as a Numeric Keypad
The numeric keypad is embedded in the keyboard and
consists of 15 keys that make number intensive input more
convenient. These dual-purpose keys are labeled in orange
on the key caps. Numeric assignments are located at the
upper right hand corner of each key as shown in the figure.
When the numeric keypad is engaged by pressing [
Fn
][
Ins/
Num LK
], the number lock LED lights up. If an external
keyboard is connected, pressing the [
Ins/Num LK
] on the
external keyboard enables/disables the NumLock on both
keyboards simultaneously. To disable the numeric keypad
while keeping the keypad on an external keyboard activated, press the [
Fn
][
Ins/Num LK
] keys on the
Notebook PC.
Keyboard as Cursors
The keyboard can be used as cursors while Number Lock is
ON or OFF in order to increase navigation ease while
entering numeric data in spreadsheets or similar applications.
With Number Lock OFF, press [
Fn
] and one of the cursor
keys shown below. For example [
Fn
][
8
] for up, [
Fn
][K] for
down, [
Fn
][
U
] for left, and [
Fn
][
O
] for right.
With Number Lock ON, use [
Shift
] and one of the cursor
keys shown below. For example [
Shift
][
8
] for up, [
Shift
][
K
]
for down, [
Shift
][
U
] for left, and [
Shift
][
O
] for right.
