WL-320gE Access Point Quick Start Guide
English
3) Wall mount option
The ASUS WL-320gE Access Point is designed to sit on a a raised flat surface like a file
cabinet.or.book.shelf..The.unit.may.also.be.converted.for.mounting.to.a.wall.or.ceiling.
Follow.these.steps.to.mount.the.ASUS.Wireless.
Access.Point.to.a.wall:
1...Look.on.the.underside.for.the.two.mounting.
hooks.
2. Mark upper holes in a flat surface.
3....Tighten.two.screws.until.only.1/4''.is.showing.
4...Latch.the.hooks.of.the.ASUS.Access.Point.
onto.the.screws.
Note:.Re-adjust.the.screws.if.you.cannot.latch.the.ASUS.Wireless.Access.Point.onto.
the.screws.or.if.it.is.too.loose.
2) Back panel
The.rear.panel.contains.the.Ethernet,.the.DC.port,.and.the.Reset.button.
LABEL Description
ETHERNET The.Ethernet.port.connects.to.an.Ethernet.device,.such.
as.to.a.switch.or.a.router.
RESET Press.the.Reset.button.to.restore.to.factory.default.
settings.
DC The.DC.port.connects.the.Access.Point.power.adapter.
