ASUS P4P8X SE motherboard user guide 1-5
1.4 Motherboard components
Before you install the motherboard, learn about its major components and
available features to facilitate the installation and future upgrades. Refer to the
succeeding pages for the component descriptions.
1. ATX 12V connector
2. CPU socket
3. North Bridge controller
4. DDR DIMM sockets
5. ATX power connector
6. Super I/O controller
7. Floppy disk connector
8. IDE connectors
9. AGP 8X slot
10. SATA connectors
11. Flash ROM
12. South Bridge controller
13. Standby power LED
14. PCI slots
15. Audio CODEC
16. LAN controller
17. PS/2 mouse port
18. Parallel port
19. RJ-45 port
20. Line In jack
21. Line Out jack
22. Microphone jack
23. USB 2.0 ports 3 and 4
24. USB 2.0 ports 1 and 2
25. Serial port
26. S/PDIF out port
27. Keyboard port
See page 1-6 for the specifications of each component.
