ASUS P/I-P55T2P4S User’s Manual 11
III. INSTALLATION
Jumpers
1) CBSIZE p. 13 Memory Cacheable Size (64MB / 512MB)
2) BBLKW p. 14 Flash ROM Boot Block Program (Disable/Enable)
3) SIO p. 14 Super Multi-I/O Selection (Enable/Disable)
4) RTCLR p. 15 Real Time Clock RAM (Operation/Clear Data)
5) FS1, FS2 p. 16 CPU External Clock (BUS) Frequency Selection
6) BF0, BF1 p. 16 CPU:BUS Frequency Ratio (1.5, 2.0, 2.5, 3.0)
7) VID p. 17 CPU Voltage Selection
Expansion Slots
1) TAG SRAM p. 13 TAG SRAM Upgrade Socket
2) SIMM Sockets p. 18 DRAM Memory Expansion Sockets
3) CPU ZIF Socket 7 p. 21 Central Processing Unit (CPU) Socket
4) ISA Slots p. 22 16-bit ISA Bus Expansion Slots
5) PCI Slots* p. 22 32-bit PCI Bus Expansion Slots
Connectors
1) KBCON p. 24 Keyboard Connector (5-pin Female)
2) PS2MOUSE p. 24 PS/2 Mouse Connector (6-pin Block)
3) PRINTER p. 25 Parallel (Printer) Port Connector (26-pin Block)
4) COM1, COM2 p. 25 Serial Port COM1 & COM2 (10-pin Blocks)
5) FLOPPY p. 26 Floppy Drive Connector (34-pin Block)
6) POWER p. 26 Motherboard Power Connector (12-pin Block)
7) Primary/Second. IDE p. 27 Primary/Secondary IDE Connectors (40-pin Blocks)
8) HDLED p. 27 SCSI/IDE Activity LED Lead
9) TB LED (PANEL) p. 28 Turbo LED/Power LED (2-pins)
10) SMI (PANEL) p. 28 SMI Switch Lead (2-pins)
11) RESET (PANEL) p. 28 Reset Switch Lead (2-pins)
12) KEYLOCK (PANEL) p. 28 Keyboard Lock Switch Lead (5-pins)
13) SPEAKER (PANEL) p. 28 Speaker Connector (4-pins)
14) FANPWR 1, 2 p. 29 12 Volt CPU Cooling Fan Connector
15) IR p. 29 Infrared Port Module Connector
16) SCSI & Wide SCSI p. 30 50-Pin SCSI and 68-Pin Wide-SCSI Connectors
17) RAID PORT p. 30 Raid Port
(Map of Board)
III. INST
ALLA
TION
* PCI Slot 1 share the same interrupt number (INTA#) with the onboard 7880 SCSI
chipset, therefore PCI Slot 1 cannot use expansion cards which require an interrupt
number. Use the other PCI Slots first. If you need all the slots, try using your display
card on PCI Slot 1 because some display cards do not use an interrupt number.
