4 ASUS A7V333 Technical Updates

A7V333 Updates

For updated processor settings, visit the ASUS web site: www.asus.com.tw

SPECIFICATIONS AND INFORMATION CONTAINED IN THIS MANUAL ARE FURNISHEDFOR INFORMA-
TIONAL USE ONLY, AND ARE SUBJECT TO CHANGE AT ANY TIME WITHOUT NOTICE, AND SHOULD
NOT BE CONSTRUED AS A COMMITMENT BY ASUSTeK COMPUTER INC. ASUS ASSUMES NO RESPONSI-
BILITY OR LIABILITY FOR ANY ERRORS OR INACCURACIES THAT MAY APPEAR IN THIS MANUAL,
INCLUDING THE PRODUCTS AND SOFTWARE DESCRIBED IN IT.

The chart below displays the configurations for the line connectors on the
yellow MIDI/Game/Audio connector port located on the back panel. The
three female connectors are available for use in the 6-Channel audio
system.

Connector Settings and Functions

Headphone/ 4-Speaker

6-Speaker

2-Speaker

Light Blue

Line In

Rear Spkr Out

Rear Speaker Out

Lime

Line Out/

Front SpkrOut Front Spkr Out Front Spkr Out

Pink

Mic In

Center Speaker Out,
Sub-woofer

Mic

Out

The reference on page 31 to the connector configuration for the C-media 6-
Channel audio set-up is completed by the section below, which was left out
of the manual:

5. Connector Configuration

5.4.2 Enter FastTrak133 BIOS and FastBuild Utility

1. Boot-up your computer once more. If this is the first time you have booted

with two hard disks correctly installed, then MBFastTrak133™ “Lite” BIOS
scans the IDE drives and displays this screen:

The heading on page 87 for the FastTrak133 BIOS is corrected below:
