5 ASUS P4V533-MX-Motherboard
Deutsch
1. Motherboard-Layout
PLED- PWR PLED+
Ground
GND
Reset
IDE_LED+ IDE_LED-
* Benötigt ATX-Stromversorgung.
Strom-LED
Reset-Schalter
ATX-Stromschalter*
IDE-LED
A
TX Power Connector
RJ-45
Top:
USB1
USB2
Bottom:
Below:Mic In
Center:Line Out
Top:Line In
DDR DIMM1 (64 bit, 184-pin module)
0 1
DDR DIMM2 (64 bit, 184-pin module)
2 3
FLOPPY1
CD1
CPU_FAN1
VIA
VT8751
AUX1
USB56
P4V533-MX
®
AUDIO1
Super
I/O
2Mbit
Flash
BIOS
PCI Slot 1
SEC_IDE
Accelerated Graphics Port
(AGP)
VIA
VT8235
Audio
Codec
CHA_FAN1
Socket 478
PCI Slot 2
PCI Slot 3
PRI_IDE
LED1
CLRCMOS1
PANEL1
PS/2
T: Mouse
B: Keyboard
COM1
P
ARALLEL
POR
T
VGA
USB3
USB4
CR2032 3V
Lithium Cell
CMOS Power
GAME1
USBPWR56
PANEL1
CLRCMOS1
Normal Clear CMOS
(Default)
1 2 2 3
USBPWR56
+5VSB
(Default)
3
2
+5V
1
2
