Asus WL-330N3G - Manual (Page 31)

4-5 ASUS WL-330N3G Mobile Wireless Router
4.2 Operation modes
The ASUS WL-330N3G is designed with six operation modes: Router, Access
Point (AP), Ethernet Adapter, Repeater, Hotspot, and 3G Sharing.
4.2.1 Router mode
In the Router mode, the ASUS WL-330N3G connects to the Internet via an ADSL
or a cable modem, and your network environment has multi-users using the same
IP to ISP.
Wireless computer
Internet
˝
ADSL/Cable modem WL-330N3G
In the Router mode:
• NAT is enabled.
• WAN is allowed using PPPoE, DHCP client, or static IP.
• UPnP and DDNS features, which are useful for home user, are supported.
To configure the ASUS WL-330N3G in Router mode:
1. Click the Router tab. The Router page appears.
Disable your PC’s proxy settings when using the web GUI. Ensure the WL-
330N3G and your PC are under the same subnet. Check the Internet protocol
(TCP/IP) settings of your local area connection.
