Universal Audio 2108 - Manual (Page 6)

2108 Specifications
Microphone Input Impedance Selectable, 1 kΩ or 4 kΩ
Hi-Z Input Impedance Selectable, 58 kΩ or 2 MΩ
Maximum Microphone Input Level +8 dBu
Maximum Output Level +26 dBm
Recommended Minimum Load 600 Ω
Frequency Response 20 Hz to 20 kHz ± .5dB
Maximum Gain 65 dB
Signal-to-Noise -165 dB EIN @ 65 dB Gain
Power Requirements DC-30 Power Supply & 2108 DC Power Cable
Dimensions 1U rack, 11.5” deep
Weight 10.85 lbs.
DC-30 Power Supply Specifications
Power Requirements 115V/230V
Dimensions 2.4” Height, 4.6” Width, 11” Length
Weight 4.5 Lbs
