Apollo 16 Hardware Manual Specifications 30
ANALOG I/O
Analog Outputs 1 – 16
Dynamic Range
118.5 dB (A–weighting)
Signal-to-Noise Ratio 118.2 dB (A–weighting)
Total Harmonic Distortion + Noise -107.5 dB @ -1 dBFS
Connector Type Two Female DB25, Tascam wiring
Monitor Outputs 1 – 2
Dynamic Range
115 dB (A–weighting)
Signal-to-Noise Ratio 115 dB (A–weighting)
Total Harmonic Distortion + Noise -105.5 dB @ -1 dBFS
Gain Range (Monitor Knob) -INF to 0 dBFS
Connector Type Two Male Balanced XLR (pin 2 hot)
All Analog Outputs
Frequency Response
20 Hz – 20 kHz, ±0.05 dB
Channel Separation (Crosstalk) -120 dB
Output Impedance 600 Ohms
Stereo Level Balance ±0.01 dB
Gain Settings +4 dBu or -10 dBV (reference level is selectable in pairs)
Max Output Voltage (Reference Level @ +4 dBu, Balanced) 20.22 dBu (18 dBV, 7.94 VRMS, 0 dBFS)
Max Output Voltage (Reference Level @ -10 dBV, Balanced) 14.22 dBu (12 dBV, 3.98 VRMS, 0 dBFS)
Max Output Voltage (Reference Level @ -10 dBV, Single-Ended) 8.22 dBu (6 dBV, 2 VRMS, 0 dBFS)
DIGITAL I/O
AES/EBU
Connector Type
XLR
Format IEC 60958 Type I
MADI
Connector Type
Dual Optical SC-Plug (ISO/IEC 9314-3)
Format AES10
Supported Modes @ Sample Rates of 88.2 kHz and Higher Standard, Legacy
Word Clock
Connector Type
BNC
Lock Range ±0.5% of any supported sample rate
Word Clock Input Termination 75 Ohms, switchable
Syncronization Sources
Internal, Word Clock, AES/EBU
(continued)
