Draw-Tite 30153 FIFTH WHEEL RAILS ONLY - Manual

© 2011 Cequent Performance Products, Inc. Made in XXX 30153N 07-01-11 Rev. A
Printed in XXX
REESE RAIL MOUNTING KIT #30153
PREMIUM-OUTBOARD MOUNTING SYSTEM
SAE J2638 RATED
INSTRUCTIONS
For Installation Assistance or Technical Help, Call 1-888-521-0510
BASERAILS QTY.
1.REESE BASERAIL
(2)
2. ½” X 2” GR. 8 CARRIAGE BOLT (10)
3. TRUCK BED SPACER (10)
4. 1/2” CONICAL TOOTHED WASHER (10)
5. 1/2” NUT (10)
Fig. 1
SHEET 1 0F 2
REESE PREMIUM FEATURES
•Kit must be mounted with REESE Series Custom mounting kits (part #
56000 series only) which are mounted outboard, allowing for fast easy
installations
•Meets latest North American testing standards, SAE J2638
•Grade 8 hardware, meets all North American requirements for
commercial & recreational towing
4
1
2
3
5
