sE Electronics Munro Egg 150 - Manual (Page 8)

Setting up your System
Running In
High quality drivers are used in the Egg systems. When new, they will reach their optimum working performance after approximately
24 hours of operation and after that should still be allowed to warm up before serious mixing is carried out.
System Adjustment Range
In Room Equalisation (offset for clarity)
Mid Frequency (Presence) Switch Settings
Reference Data
Frequency Response 45Hz to 20KHz (-3dB points)
Low Frequency Room Calibration +0/-10dB at 63 Hz continuously variable
High Frequency Calibration +1/-5dB at 10kHz continuously variable
Mid Frequency Adjustment +/- 1.5dB at 2kHz Centre Frequency
The Egg 150 System
Operation Manual
5
