GB
13
Description of the
appliance
Overall view
• The ELECTRIC PLATE vary in diameter and
power: "normal" and "fast". The latter can be
identified by a red boss in the center of the hot
plate itself.
! The position of the corresponding electric hot plate
is indicated on each control knob.
• The ELECTRIC PLATE ON indicator light switches
on whenever the knob is moved from the 'off'
position.
• The ELECTRIC PLATE control knob is a device
used to regulate power.
The knob may be turned clockwise or anti-
clockwise and set to six different positions:
Setting Normal or Fast Plate
0 Off
1 Low
2 - 5 Medium
6 High
! Please refer to the "Practical advice on using the
appliance" section for a list of the relative positions
and their recommended uses.
Control knobs for the cook-top
ELECTRIC PLATE
Pilot lamp of the
ELECTRIC PLATE
ELECTRIC PLATE
