3-piece hand evaluation set

Hydraulic hand dynamometer – The hand dynamometer can be used to measure grip strength. It is calibrated in pounds and kilograms
of force.

The grip handle is adjustable to accommodate various size hands. Always use the same grip setting and dynamometer when evaluating a
specific subject for hand trauma or disease.

Set the handle to the desired position. Have subject hold the dynamometer in a comfortable position. The shoulder should be adducted
and neutrally rotated, the elbow flexed to 90 degrees, and the forearm and wrist should be in a neutral position. Have the subject squeeze
the handle using his/her maximum effort. The red maximum pointer will remain at the subject's maximum reading until it is reset. The red
maximum pointer must be reset before each grip test. Rotate the small knurled knob on top of the dial indicator in a counterclockwise
direction until it rests against the black pointer at the zero marking. Each grip test should be repeated three times and the average result
should be used.

Grip strength varies depending upon the size of the object being grasped. The adjustable handle allows for quantification of grip strength
for different sized objects.

To determine whether a subject is exerting maximum effort use the following protocol:
• Take readings with adjustable handle in all five positions
• Test the normal hand and then the injured hand
• Repeat the test after five minutes

If maximum effort was exerted there should be approximately a 10% variation in the two sets of test results.

Hydraulic Pinch Gauge – The finger pinch gauge can be used to measure pinch strength. It is calibrated in pounds and kilograms of
force.

Apply pinch force at the pinch groove while holding the pinch gauge between your thumb and finger(s). When force is applied further
toward the tip the reading will be slightly higher. When force is applied further toward the rear the reading will be slightly lower.

The gauge must be “zeroed” before each pinch test. Grasp the knurled ring of the dial indicator and rotate it until the zero on the dial indi-
cator is directly under the black pointer.

The red maximum pointer must be reset before each pinch test. Rotate the small knurled knob on top of the dial indicator in a counter-
clockwise direction until it rests against the black pointer at the zero marking. The red maximum pointer will remain at the subject's maxi-
mum reading until it is reset.
Use the pinch gauge to perform the three basic pinch tests:
• Tip Pinch --- thumb tip to index fingertip
• Key Pinch --- thumb pad to lateral aspect of middle phalanx of index finger
• Palmer Pinch --- thumb pad to pads of the index and middle fingers

NORMS FOR ADULT GRIP STRENGTH performance of all subjects (lbs)

men

women

age

hand

mean

SD

low-high

mean

SD

low-high

20-24

dominant

121.0

20.6

91-167

70.4

14.5

46-95

non-dominant

104.5

21.8

71-150

61.0

13.1

33-88

25-29

dominant

120.8

23.0

78-158

74.5

13.9

48-97

non-dominant

110.5

16.2

77-139

63.5

12.2

48-97

30-34

dominant

121.8

22.4

70-170

78.7

19.2

46-137

non-dominant

110.4

21.7

64-145

68.0

17.7

36-115

35-39

dominant

119.7

24.0

76-176

74.1

10.8

50-99

non-dominant

112.9

21.7

73-157

66.3

11.7

49-91

40-44

dominant

116.8

20.7

84-165

70.4

13.5

38-103

non-dominant

112.8

18.7

73-157

62.3

13.8

35-94

45-49

dominant

109.9

23.0

65-155

62.2

15.1

39-100

non-dominant

100.8

22.8

58-160

56.0

12.7

37-83

50-54

dominant

113.6

18.1

79-151

65.8

11.6

38-87

non-dominant

101.9

17.0

70-143

57.3

10.7

35-76

55-59

dominant

101.1

26.7

59-154

57.3

12.5

33-86

non-dominant

83.2

23.4

43-128

47.3

11.9

31-76

60-64

dominant

89.7

20.4

51-137

55.1

10.1

37-77

non-dominant

76.8

20.3

27-116

45.7

10.1

29-66

65-69

dominant

91.1

20.6

56-131

49.6

9.7

35-74

non-dominant

76.8

19.8

43-117

41.0

8.2

29-63

70-75

dominant

75.3

21.5

32-108

49.6

11.7

33-78

non-dominant

64.8

18.1

32-93

41.5

10.2

23-67

75+

dominant

65.7

21.1

40-135

42.6

11.0

25-65

non-dominant

55.0

17.0

31-119

37.6

8.9

24-61

ALL

dominant

104.3

28.3

32-176

62.8

17.0

25-137

non-dominant

93.1

27.6

27-160

53.9

15.7

23-115

NORMS FOR ADULT PINCH STRENGTH Key Pinch strength performance of all subjects (lbs)

men

women

age

hand

mean

SD

low-high

mean

SD

low-high

20-24

dominant

26.0

3.5

21-34

17.6

2.0

14-23

non-dominant

24.8

3.4

19-31

16.2

2.1

13-23

25-29

dominant

26.7

4.9

19-41

17.7

2.1

14-22

non-dominant

25.0

4.7

19-39

16.6

2.1

13-22

30-34

dominant

26.4

4.8

20-36

18.7

3.0

13-25

non-dominant

26.2

5.1

17-36

17.8

3.6

12-26

35-39

dominant

26.1

3.2

21-32

16.6

2.0

12-21

non-dominant

25.6

3.9

18-32

16.0

2.7

12-22

40-44

dominant

25.6

2.6

21-31

16.7

3.1

10-24

non-dominant

25.1

4.0

19-31

15.8

3.1

8-22

45-49

dominant

25.8

3.9

19-35

17.6

3.2

13-24

non-dominant

24.8

4.4

18-42

16.6

2.9

12-24

50-54

dominant

26.7

4.4

20-34

16.7

2.5

12-22

non-dominant

26.1

4.2

20-37

16.1

2.7

12-22

55-59

dominant

24.2

4.2

18-34

15.7

2.5

11-21

non-dominant

23.0

4.7

13-31

14.7

2.2

12-19

60-64

dominant

23.2

5.4

14-37

15.5

2.7

10-20

non-dominant

22.2

4.1

16-33

14.1

2.5

10-19

65-69

dominant

23.4

3.9

17-32

15.0

2.6

10-21

non-dominant

22.0

3.6

17-28

14.3

2.8

10-20

70-75

dominant

19.3

2.4

16-25

14.5

2.9

8-22

non-dominant

19.2

3.0

13-28

13.8

3.0

9-22

75+

dominant

20.5

4.6

9-31

12.6

2.3

8-17

non-dominant

19.1

3.0

13-24

11.4

2.6

7-16

ALL

dominant

24.5

4.6

9-41

16.2

3.0

8-25

non-dominant

23.6

4.6

11-42

15.3

3.1

7-26

NORMS FOR ADULT PINCH STRENGTH Tip Pinch strength performance of all subjects (lbs)

men

women

age

hand

mean

SD

low-high

mean

SD

low-high

20-24

dominant

18.0

3.0

11-23

11.1

2.1

8-16

non-dominant

17.0

2.3

12-33

10.5

1.7

8-14

25-29

dominant

18.3

4.4

10-34

11.9

1.8

8-16

non-dominant

17.5

5.2

12-36

11.3

1.8

9-18

30-34

dominant

17.4

6.7

12-25

12.6

3.0

8-20

non-dominant

17.6

4.8

10-27

11.7

2.8

7-17

35-39

dominant

18.0

3.6

12-27

11.6

2.5

8-19

non-dominant

17.7

3.8

10-24

11.9

2.4

8-16

40-44

dominant

17.8

4.0

11-25

11.5

2.7

5-15

non-dominant

17.7

3.5

12-25

11.1

3.0

6-17

45-49

dominant

18.7

4.9

12-30

13.2

3.0

9-19

non-dominant

17.6

4.1

12-28

12.1

2.7

7-18

50-54

dominant

18.3

4.0

11-24

12.5

2.2

9-18

non-dominant

17.8

3.9

12-26

11.4

2.4

7-16

55-59

dominant

16.6

3.3

11-24

11.7

1.7

9-16

non-dominant

15.0

3.7

10-26

10.4

1.4

8-13

60-64

dominant

15.8

3.9

9-22

10.1

2.1

7-17

non-dominant

15.3

3.7

9-23

9.9

2.0

6-15

65-69

dominant

17.0

4.2

11-27

10.6

2.0

7-15

non-dominant

15.4

2.9

10-21

10.5

2.4

7-17

70-75

dominant

13.8

2.6

11-21

10.1

2.6

7-15

non-dominant

13.3

2.6

10-21

9.8

2.3

6-17

75+

dominant

14.0

3.4

7-21

9.6

2.8

4-16

non-dominant

13.9

3.7

8-25

9.3

2.4

4-13

ALL

dominant

non-dominant

NORMS FOR ADULT PINCH STRENGTH Palmer Pinch strength performance of all subjects (lbs)

men

women

age

hand

mean

SD

low-high

mean

SD

low-high

20-24

dominant

26.6

5.3

18-45

17.2

2.3

14-23

non-dominant

25.7

5.8

15-42

16.3

2.8

11-24

25-29

dominant

26.0

4.3

19-35

17.7

3.2

13-29

non-dominant

25.1

4.2

19-36

17.0

3.0

13-26

30-34

dominant

24.7

4.7

16-34

19.3

5.0

12-34

non-dominant

25.4

5.7

15-37

18.1

4.8

12-32

35-39

dominant

26.2

4.1

19-36

17.5

4.2

13-29

non-dominant

25.9

5.4

14-40

17.1

3.4

12-24

40-44

dominant

24.5

4.3

17-37

17.0

3.1

10-23

non-dominant

24.8

4.9

15-37

16.6

3.5

14-25

45-49

dominant

24.0

3.3

19-33

17.9

3.0

12-27

non-dominant

23.7

3.8

8-33

17.5

2.8

12-24

50-54

dominant

23.8

5.4

15-36

17.3

3.1

12-23

non-dominant

24.0

5.8

16-36

16.4

2.9

12-22

55-59

dominant

23.7

4.8

16-34

16.0

3.1

11-26

non-dominant

21.3

4.5

12-25

15.4

3.0

11-21

60-64

dominant

21.8

3.3

16-28

14.8

3.1

10-20

non-dominant

21.2

3.2

15-27

14.3

2.7

10-20

65-69

dominant

21.4

3.0

15-25

14.2

3.1

8-20

non-dominant

21.2

4.1

14-30

13.7

3.4

8-22

70-75

dominant

18.1

3.4

14-27

14.4

2.6

9-19

non-dominant

18.8

3.3

13-27

14.0

1.9

10-17

75+

dominant

18.7

4.2

9-26

12.0

2.6

8-17

non-dominant

18.3

3.8

10-26

11.5

2.6

6-16

ALL

dominant

23.4

5.0

9-45

16.3

3.8

8-34

non-dominant

23.0

5.3

10-42

15.7

3.6

6-32

Finger Goniometer – The finger goniometer can be used to measure active or passive joint range of motion (ROM). It measures joint flex-
ion and hyperextension. It is calibrated in degrees.

Align the fulcrum of the goniometer with the anatomical fulcrum of the joint being measured. Place the flat arm of goniometer that is attached
to the dial indicator on the center of the limb (or extremity) to me measured. Hold both arms of the goniometer and move the joint through
its entire range-of-motion (this can be done actively by the subject or passively by the examiner.) The range of motion can be read directly
from the dial indicator
