3

Coils for demountable transformer

(transformer core with yoke and clamps)

Instruction sheet

06/05 JH

8497410 Coil with 72 turns, tapped at 6/30/54/66/72

8497430 Coil with 600 turns, tapped at 200

8497440 Coil with 1200 turns, tapped at 400

8497450 Coil with 6000 turns, tapped at 2000

8497450

8497440

8497430

8497410

Coils with a variety of winding turns and intermediate
taps. A suitable choice of coil enables all experiments to
be performed safely at low voltage. Simple whole-num-
ber winding and intermediate tap ratios allow the trans-
former laws to be derived in clear and understandable
fashion.

1. Safety instructions

The safety of operators and of the coils themselves
can only be guaranteed when they are used accord-
ing to the instructions.

Depending on the set-up of the transformer, it may
be possible to come into contact with dangerous
voltages at the secondary coil.

Coils 8497430, 8497440, 8497450 can be subject to
high or low voltages when used as secondary coils.

They are not suitable for experiments performed by
students.

The resulting magnetic fields can cause damage to or
even destroy electrical/electronic components and
equipment or electromagnetic storage media. Such
items must be kept away from the coil by at least the
amount specified for safety.

Always use safety cables for experiments.

Do not exceed the maximum voltage over any length
of time.

If the coils should become overloaded, they must be
allowed to cool before switching on the current again.

Do not cover the air vents.

Any modifications to the transformer set-up must be
made with the primary voltage switched off.

Do not open the coils’ cases.
