3B Scientific Measuring Amplifier S User Manual
Page 2
Elwe Didactic GmbH • Steinfelsstr. 6 • 08248 Klingenthal • Germany •
www.elwedidactic.com
3B Scientific GmbH • Rudorffweg 8 • 21031 Hamburg • Germany •
www.3bscientific.com
Technical amendments are possible.
3. Operation
3.1 Voltage amplifier
•
Apply the supply voltage (12 V AC).
•
Select the maximum measuring range (100 •A,
1 V), in order to avoid overload.
•
Connect the voltmeter (1 V DC or 3 V AC).
•
Connect the measurement set-up to input U.
•
Select the appropriate measuring range.
3.2 Current amplifier
•
Apply the supply voltage (12 V AC).
•
Select the maximum measuring range (100 •A,
1 V), in order to avoid overload.
•
Connect the voltmeter (1 V DC or 3 V AC).
•
Connect the measurement set-up to input I.
•
Select the appropriate measuring range.
