Eveready Super Heavy Duty AA - Manual

AA
SUPER HEAVY DUTY
Chemical System: Zinc-Manganese Dioxide (Zn/MnO
2 )
(No Added Mercury or Cadmium)
Designation: ANSI-15D, IEC-R6
Battery Voltage: 1.5 Volts
Operating Temp: -18ºC to 55ºC (0ºF to 130ºF)
Average Weight: 15.0 grams (0.5 oz.)
Volume: 8.0 cubic centimeters (0.5 cubic inch)
Average Capacity: 1,100 mAh to 0.8 volts
(Rated capacity at 25 mA continuous at 21ºC)
Cell: One No. 15 (size "AA")
Jacket: Metal
INTERNAL RESISTANCE VS. TEMPERATURE
The measurement is an approximation of the
battery's actual internal resistance. It is sensitive
to the loads and operator technique.
Schedule: Background Load 750 ohms
Pulse Load 4.0 ohms
Pulse Duration 1 second
Industry Standard Dimensions
Copyright © Eveready Battery Co. - All rights reserved
Eveready 1215
Important Notice
This data sheet contains information specific to batteries manufactured at the time of its publication.
Contents herein do not constitute a warranty.
45ºC (113ºF)
Temperature
21ºC (70ºF)
0ºC (32ºF)
-21ºC (-4ºF)
mm (inches)
5.0
Typical Ri (ohms)
0.4
0.5
0.8
0.1
1
10
100
1000
10000
1 10 100 1000
Se
rv
ic
e
, H
o
u
rs
Discharge Resistance, Ohms
CONSTANT RESISTANCE PERFORMANCE
Typical Service
0.8 Cutoff Voltage
1.0 Cutoff Voltage
1.2 Cutoff Voltage
0.1
1
10
100
1000
10000
1 10 100 1000
Se
rv
ic
e
, H
o
u
rs
Discharge Current, mA
CONSTANT CURRENT DISCHARGE
Typical Service
0.8 Cutoff Voltage
1.0 Cutoff Voltage
1.2 Cutoff Voltage
1-800-383-7323 USA/CAN
www.energizer.com
PRODUCT DATASHEET
Form No. EBC - 3109H Page 1 of 2
