How to install the SSD
A)15-pin SATA Power Connector B) 7-pin SATA Data Connector
D) 7-pin SATA Data Input Connector from HDD
OR
HDD
HDD
4-1
If the products shown above are different than the products included in the packaging, please
contact the seller or retailer for replacement.
A B C
HDD
E G D F
E) Top Cover F) Unit Body
C) Air Flow Vents
G) Screw holes
SSD
HDD
HDD
4-2 4-3
