SFP+, 10GBASE-SR 10G Ethernet Module
850mn, 300m, MMF, LC RoHS6
_______________________________________________________
Approved Optics, Inc. www.ApprovedOptics.com
Page 4 of 8
Differential Input Voltage
Swing
VID
150
900
mV
Differential Input S-
parameter
0.01 –
3.9GHz
SDD11
-10
dB
3.9 –
11.1GHz
1)
1)
dB
Differential to Common
Mode Conversion 2)
0.01 –
11.1Ghz
SCD11
-10
dB
Total Jitter
TJ
0.28
UI(p-p)
Data Dependant Jitter
DDJ
0.1
UI(p-p)
Uncorrelated Jitter
UJ
0.023 RMS
Eye Mask
See SFP+ MSA
X1
0.14
UI
X2
0.35
UI
SFI Module Receiver Output Characteristics
Parameter
Conditions
Symbol
Min
Typ
Max
Units
Supported Data Rate
1
10.312
5
11.3 Gbd
Reference Differential
Output Impedance
Zd
100
Termination Mismatch
ΔZd
5
%
Output AC Common Mode
Output Voltage
15
mV
(RMS)
Differential Output Amplitude
RLoad=100Ohm ,
Differential
VOSPP
350
650
800
mV
Output Rise and Fall time
20% to 80%
tRH, tFH
24
35
ps
Differential Input S-
parameter
0.01 – 3.9GHz
SDD22
-10
dB
3.9 – 11.1GHz
1)
dB
Common Mode Output
Return Loss2)
0.01 – 6.5Ghz
SCC22
-7
dB
6.5 – 11.1Ghz
-3
dB
1) Return Loss given by equation Sxx22(dB) = -8+13.33 Log10(f/5.5), with f in GHz;
2) Common mode reference impedance is 25Ω. Common mode return loss helps absorb
reflection and noise improving EMI.
