Powersolve PKS11-USB 5 Volt 2.1 Amp - Manual

Email: [email protected]
www.powersolve.co.uk
USB Charger (Wall Mounting)
PKS11-USB 10.5 Watt USB Charger
Single 5V 2.1A output
Features:-
• Universal 90-264VAC input
• Interchangeable AC heads
• Meets Level V efficiency standards
• Output via standard USB socket
• Conforms to RoHS standards
• Full International Safety Approvals
• EMC to EN55022’B’, CISPR22 ‘B’ & FCC ‘B’
Electrical Specification
Input Voltage & Frequency 90-264VAC, 50/60Hz
Input Current 0.5A max
No Load Input Power 0.3 Watts max
Inrush Current on turn on 60A
Line Regulation ±5%
Load Regulation ±5%
Ripple & Noise 120mV pk-pk
Efficiency 73.7% min 25-100%
Turn On Delay 4000mS
Start Up Rise Time 20 mSec
Hold Up 20 mSec
Output Overshoot <10 %
Temperature Coefficient ±0.05%/ºC
Over Voltage Protection Clamped by internal protection circuit
Short Circuit Protection With auto recovery
Over Current Protection Protected from ≤120% of rated output
Safety Approvals UL/cUL60950-1, TUV EN60950-1, A60950, CE
EMC/EMI EN55022’B’, CISPR22’B’ & FCC’B’
Dielectric Withstand Voltage 3000VAC 5mA primary to secondary for 1 minute
Safety Class Class II
Leakage Current <0.25mA
Operating Temperature 0 to 40ºC
Storage Temperature -20 to 80ºC
Relative Humidity 10-90% non condencing
Energy Efficiency Level V
