MAX Power HYD225 Hydraulic Tunnel Thruster User Manual
Page 10
MANUAL SUPER POWER Series 225 HYD 01/05/2004
SPARE PARTS LIST
SUPER POWER Series 225HYD DUO
N° DESCRIPTION
Composite Leg
MPHYC1100
Classic Leg
MPHY1100
REFERENCES
3 Motor
fixing
bolts
1
4
MPOP5240
4 Hydraulic motor
1
1
MPHY 6010
5 Adapter plate
1
1
MPHY 5012
8 Upper drive coupling hydraulic model
1
1
MP 205027
10 Rubber coupling
1
1
MP 205023
11 Drive key
1
1
MP11 5010
12 Lower drive coupling
1
1
MP 205025
13 Motor
support
1
1
MP118019
15 Composite Drive Leg
1
MP11 8100
16 Drive shaft seal
1
MPOP 5540
17 Drive shaft
1
MPOP 5420
18 Upper bearing
1
MPOP 5430
19 Lower bearing
1
MPOP 5431
20 Upper gear
1
MPOP 5080
21 Clip
1
MP11
5030
22 Composite Fixing Bolts
2
MP114010
22 Fixing
screw
2
MPOP
5490
23 Fibre joint leg / tunnel 1,5 mm
1
1
MPOP 2061
24 Leg housing
1
MPOP 5450
25 Propeller D 250
2
2
MPOP 5400
26 Propeller nut
2
2
MPOP 5410
27 Propeller drive pin
2
2
MPOP 5530
28 Oil seal
2
MPOP 5520
29 Screw Cap
4
MPOP 5480
30 Propeller drive shaft
1
MP13 5010
31 Shaft key
1
MPOP 5470
32 Lower drive gear
1
MPOP 5090
33 Shim
2
MPOP
5500
34 Propeller shaft bearing
2
MPOP 5440
35 O-ring
2
MPOP
5460
36 Cap
2
MPOP
5510
37 Copper washer
1
MPOP 2050
38 Drain plug
1
MPOP 5300
39 Anode
1
MPOP
5390
40 Anode
screw
1
MPOP5311
41 Complete classic bronze drive leg
1
MP11 8030
