PowerWalker VI 600 SW - Manual (Page 8)

EN
8. Specifications
Model VI 600 SW VI 800 SW
CAPACITY 600 VA / 360 W 800 VA / 480 W
INPUT
Voltage
220~240 VAC
Voltage Range 162~290 VAC
Frequency Range 50/60Hz±1Hz
OUTPUT
Voltage Regulation
+/-10%
Transfer Time Typical 2-6 ms, 10 ms max.
Waveform Pure Sinewave
Protection Short circuit and overload protection
BATTERY
Type & Number
12V/ 7Ah x 1 12V/ 9Ah x 1
Charging Time 4 hours recover to 90% capacity
Protection Discharge and overcharge protection
Backup Time (est. 120W) 10 min 15 min
PHYSICAL
LCD Indicator
Input/output voltage, AC mode, Load level, Battery capacity
Dimension (DxWxH) 328mm x 100mm x 145mm
ENVIRONMENT
Humidity
0-90 % RH @ 0-40° C (non-condensing)
Noise Level Less than 40 dB
