8. Specifications
Model VI 450 LCD VI 650 LCD VI 850 LCD
CAPACITY 450 VA / 240 W 650 VA / 360 W 850 VA / 480 W
INPUT
Voltage
220~240 VAC
Voltage Range 162~290 VAC
Frequency Range 50/60Hz±1Hz
OUTPUT
Voltage Regulation
+/‐10%
Transfer Time Typical 2‐6 ms, 10 ms max.
Waveform Simulated Sine Wave
Protection Short circuit and overload protection
BATTERY
Type & Number
12V / 4.5Ah x 1 12V/ 7Ah x 1 12V/ 9Ah x 1
Charging Time 4‐6 hours recover to 90% capacity
Protection Discharge and overcharge protection
Backup Time (est. 120W) 5 min 10 min 15 min
PHYSICAL
LCD Indicator
Input/output voltage, AC mode, Load level, Battery capacity
Dimension (DxWxH) 287mm x 100mm x 142mm
ENVIRONMENT
Humidity
0‐90 % RH @ 0‐40° C (non‐condensing)
Noise Level Less than 40 dB
Model VI 1000 LCD VI 1500 LCD VI 2000 LCD
CAPACITY 1000 VA / 600 W 1500 VA / 900 W 2000 VA / 1200 W
INPUT
Voltage
220/230/240 VAC
Voltage Range 162~290 VAC
Frequency Range 50/60 Hz (Auto sensing)
OUTPUT
Voltage Regulation
+/‐10%
Frequency Range 50 or 60 Hz +/‐1 Hz
Transfer Time Typical 2‐6 ms, 10 ms max.
Waveform Simulated Sine Wave
BATTERY
Type & Number
12V / 7Ah x 2 12V / 9Ah x 2 12V / 9Ah x 2
Charging Time 4‐6 hours recover to 90% capacity
Protection Overload, discharge and overcharge protection
Backup Time (est. 240W) 11 min 18 min 20 min
PHYSICAL
LCD Indicator
Input/output voltage, AC mode, Load level, Battery capacity
Dimension (DxWxH) 350x146x160 mm 397mm x 146mm x 205 mm
ENVIRONMENT
Humidity
0‐90 % RH @ 0‐40° C (non‐condensing)
Noise Level Less than 40 dB
