9. Specifications
Model VI 400 SE VI 600 SE VI 800 SE
CAPACITY 400VA / 240W 600VA / 360W 800VA / 480W
INPUT
Voltage
220~240 VAC
Voltage Range 170~280 VAC
Frequency Range 50/60Hz±1Hz
OUTPUT
Voltage Regulation
+/-10%
Transfer Time Typical 2-6ms, 10ms max.
Waveform Modified Sine Wave
Protection Short circuit and overload protection
BATTERY
Type & Number
12V / 4.5Ah x 1 12V/ 7Ah x 1 12V/ 9Ah x 1
Charging Time 6 hours recover to 90% capacity
Protection Discharge and overcharge protection
Backup Time (est. 120W) 8 min 16 min 20 min
PHYSICAL
LED Indicator
Green LED (AC Mode, Backup Mode)
Dimension (DxWxH) 333mm x 111mm x 143mm
ENVIRONMENT
Humidity
0-90 % RH @ -10° to 40° C (non-condensing)
Noise Level Less than 40dB
Model VI 1000 SE VI 1400 SE VI 2000 SE
CAPACITY 1000VA / 600W 1400VA / 840W 2000VA / 1200W
INPUT
Voltage
220/230/240 VAC
Voltage Range 162~290 VAC
Frequency Range 50/60 Hz (Auto sensing)
OUTPUT
Voltage Regulation
+/-10%
Frequency Range 50 or 60 Hz +/-1 Hz
Transfer Time Typical 4-8ms, 10ms max.
Waveform Stepped Sine Wave
BATTERY
Type & Number
12V / 7Ah x 2 12V / 9Ah x 2 12V / 9Ah x 2
Charging Time 10h to 90% capacity 6h to 90% capacity 6h to 90% capacity
Protection Overload, discharge and overcharge protection
Backup Time (est. 240W) 11 min 18 min 20 min
PHYSICAL
LCD Indicator
Input/output voltage, AC mode, Load level, Battery capacity
Dimension (DxWxH) 230mm x 452mm x 292 mm
ENVIRONMENT
Humidity
0-90 % RH @ 0-40° C (non-condensing)
Noise Level Less than 45dB
