9

XHD6420 

OPERATION 

Automatically Store 

Stations

Preset Scan

Band

 Display

HD Seek Mode

Press AS/PS for more than two seconds to automatically
store the six strongest stations in the current band.
Automatic local tuning is activated during initial band scan.

Press AS/PS momentarily to scan presets 1-6 on the
current band, pausing for five seconds at each. Press AS/PS
again to cancel.

Press BAND to select FM1, FM, FM, AM1 or AM.

When the unit is tuned to an analog station, press DISP to
toggle the display between the following options:

When the unit is tuned to an HD Radio station, press DISP to
toggle the display between the following options:

When information is unavailable, "NO DATA" appears in the
display.

Press HD SEEK to activate digital-only tuning mode. The HD 
SEEK
icon will appear on the display, indicating that the unit
will skip over analog stations and tune to HD Radio stations
only. Follow the instructions on page 9 to access seek,
manual and scan tuning.

•  Storing and Recalling Station Presets
HD Radio multicast stations (HD and HD) can also
be stored as presets. When a preset multicast station
is recalled, "LINKING" appears in the display until the
download process is complete (approximately 5 seconds).
  Note: If the HD radio signal on the preset is unavailable,
the unit reverts to the previous analog or digital station.
Automatically Store Stations
While in HD SEEK mode, press AS/PS to automatically
store HD Radio stations to presets 1-6. Multicast
channels (HD and/or) HD are not stored but can be
accessed by pressing TUNE

ll

from the HD1 station.

HD Radio™ AM/FM Tuner Operation

CLOCK

FREQUENCY

STATION

NAME

ARTIST

SONG

TITLE

CLOCK

FREQUENCY

PROGRAM

TYPE
