USB Ranger ® 2204
Cat 5 USB 2.0 Extender
Ranger 2204 extends USB 2.0
beyond the desktop up to 100m
over standard Cat 5 cable using
ExtremeUSB
® technology.
Ranger 2204 Features
Powered by ExtremeUSB • ® . Long reach USB 2.0 enabled by Icron’s LionsGate™ USB 2.0 Extension ASIC.
Extends USB 2.0 high-speed and USB 1.1 (low-speed, full speed) devices up to 100m over Cat 5 cable. •
Operates with USB 2.0 high-speed host controllers and USB 1.1 classic hosts. •
Supports all USB device types: Control, Interrupt, Bulk and Isochronous at up to 480Mbps. •
True plug and play, ready to operate right out of the box. No new driver installation required. •
Supports all major operating systems including Windows • ® , Mac OS ® , and Linux ® .
Integrated hub provides four remote USB 2.0 ports. Number of devices can be increased using •
additional USB hubs.
AC power adapter at remote unit provides standard 500mA to each USB port.
•
Power adapter at local unit is not required for normal operation. •
Ideal for a wide variety of USB devices, from printers, scanners, hard drives, and audio devices, •
to touch screens, web cams, and game controllers.
