Alled Moulded HFPU108 User Manual
Amu series, Design features

222 North Union Street • Bryan, Ohio 43506
(419) 636-4217 • Fax (419) 636-2450
http://enclosures.alliedmoulded.com
AMU Series:
AMU Series:
Aluminum Hinged
Aluminum Hinged
Front Panel
Front Panel
• Hinged front panels available for Ultraline
®
sizes 10x8x4 through 20x16x10
• Panels designed to offer both a professional instrumentation display
and a protective covering for electric wiring inside the enclosure
• The Ultraline
®
1 inch raised cover allows room for digital display assembly
on the hinge front panel surface
• Ultraline
®
enclosures offer optional viewing window covers and clear
polycarbonate covers for a professional instrumentation display
• Latch design secures panel in place with one quarter turn
• Panel modifications available include: cut-in holes, panel height, and screen print
• Completely field-installable panel design with no required enclosure
modifications
• Compliant with RoHS directive (Restriction of Hazardous Substances)
Ordering Part Numbers:
HFPU108
HFPU108
HFPU120
HFPU120
HFPU142
HFPU142
HFPU164
HFPU164
HFPU186
HFPU186
HFPU206
HFPU206
Design Features
Design Features
ULHFP1206
