SPP-100 Specifications
Bus Interface: 16-bit PCMCIA, Release 8 and backward compliant
OS Support: Windows 95/98/Me/NT/2000/XP/Vista
Windows CE (see web for device compatibility)
Linux (standard modes only)
OS/2
HP Palmtop
Data Rate: 700 kbps (max)*
* Actual baud rates can be affected by cabling and other factors
Ports: 1 Parallel Port
Modes: EPP Mode
Standard Unidirectional Parallel Port Mode
Standard Bidirectional Parallel Port Mode
Interrupt Levels: IRQ 3-7, IRQ 9-12, IRQ 14, IRQ 15
Power Requirements: 35 mA @ +5 V, 25 mA @ +3.3 V
Certifications: CE, FCC Class B, RoHS and WEEE Compliant
www.quatech.com
February 2007
Made in USA [email protected]
Connector: Standard DSUB-25 connector via included pigtail
cable off the card as follows:
PIN 1: STROBE
PIN 2: D0
PIN 3: D1
PIN 4: D2
PIN 5: D3
PIN 6: D4
PIN 7: D5
PIN 8: D6
PIN 9: D7
PIN 10: ACK
PIN 11: BUSY
PIN 12: PERROR
PIN 13: SELECTIN
PIN 14: AUTOFEED
PIN 15: NFAULT
PIN 16: INT
PIN 17: SELECT
PIN 18: GND
PIN 19: GND
PIN 20: GND
PIN 21: GND
PIN 22: GND
PIN 23: GND
PIN 24: GND
PIN 25: GND
Ordering Information:
SPP-100: EPP PCMCIA card with DB25 female cable
