Absolute Maximum Ratings
(Note 1)
Supply Voltage +12V to −0.2V
Output Voltage (+V
S
+ 0.6V) to
−0.6V
Output Current 10 mA
Input Current at any pin (Note 2) 5 mA
Storage Temperature −65˚C to +150˚C
Maximum Junction Temperature
(T
JMAX
) +125˚C
ESD Susceptibility (Note 3) :
Human Body Model 2500V
Machine Model 250V
Lead Temperature:
TO-92 Package:
Soldering (10 seconds) +260˚C
SOT-23 Package (Note 4):
Vapor Phase (60 seconds) +215˚C
Infrared (15 seconds) +220˚C
Operating Ratings
(Note 1)
Specified Temperature Range: T
MIN
≤ T
A
≤ T
MAX
LM61C −30˚C ≤ T
A
≤ +100˚C
LM61B −25˚C ≤ T
A
≤ +85˚C
Supply Voltage Range (+V
S
) +2.7V to +10V
Thermal Resistance, θ
JA
(Note 5)
SOT-23
TO-92
450˚C/W
180˚C/W
Electrical Characteristics
Unless otherwise noted, these specifications apply for +V
S
= +3.0 V
DC
. Boldface limits apply for T
A
= T
J
= T
MIN
to T
MAX
; all
other limits T
A
= T
J
= 25˚C.
Parameter Conditions Typical
(Note 6)
LM61B LM61C Units
(Limit) Limits Limits
(Note 7) (Note 7)
Accuracy (Note 8) ± 2.0 ± 3.0 ˚C (max)
± 3.0 ± 4.0 ˚C (max)
Output Voltage at 0˚C +600 mV
Nonlinearity (Note 9) ± 0.6 ± 0.8 ˚C (max)
Sensor Gain +10 +9.7 +9.6 mV/˚C (min)
(Average Slope) +10.3 +10.4 mV/˚C (max)
Output Impedance +3.0V ≤ +V
S
≤ +10V
−30˚C ≤ T
A
≤ +85˚C, +V
S
= +2.7V
+85˚C
≤ T
A
≤ +100˚C, +V
S
= +2.7V
0.8
2.3
5
0.8
2.3
5
k Ω (max)
k Ω (max)
k Ω (max)
Line Regulation (Note 10) +3.0V ≤ +V
S
≤ +10V ± 0.7 ± 0.7 mV/V (max)
+2.7V ≤ +V
S
≤ +3.3V ± 5.7 ± 5.7 mV (max)
Quiescent Current +2.7V ≤ +V
S
≤ +10V 82 125 125 µA (max)
155 155 µA (max)
Change of Quiescent Current +2.7V ≤ +V
S
≤ +10V ± 5 µA
Temperature Coefficient of 0.2 µA/˚C
Quiescent Current
Long Term Stability (Note 11) T
J
=T
MAX
=+100˚C,
for 1000 hours
± 0.2 ˚C
Note 1: Absolute Maximum Ratings indicate limits beyond which damage to the device may occur. Operating Ratings indicate conditions for which the device is
functional, but do not guarantee specific performance limits. For guaranteed specifications and test conditions, see the Electrical Characteristics. The guaranteed
specifications apply only for the test conditions listed. Some performance characteristics may degrade when the device is not operated under the listed test
conditions.
Note 2: When the input voltage (V
I
) at any pin exceeds power supplies (V
I
< GND or V
I
> +V
S
), the current at that pin should be limited to 5 mA.
Note 3: The human body model is a 100 pF capacitor discharged through a 1.5 k Ω resistor into each pin. The machine model is a 200 pF capacitor discharged
directly into each pin.
Note 4: See AN-450 “Surface Mounting Methods and Their Effect on Product Reliability” or the section titled “Surface Mount” found in any post 1986 National
Semiconductor Linear Data Book for other methods of soldering surface mount devices.
Note 5: The junction to ambient thermal resistance ( θ
JA
) is specified without a heat sink in still air.
Note 6: Typicals are at T
J
= T
A
= 25˚C and represent most likely parametric norm.
Note 7: Limits are guaranteed to National’s AOQL (Average Outgoing Quality Level).
Note 8: Accuracy is defined as the error between the output voltage and +10 mV/˚C times the device’s case temperature plus 600 mV, at specified conditions of
voltage, current, and temperature (expressed in ˚C).
Note 9: Nonlinearity is defined as the deviation of the output-voltage-versus-temperature curve from the best-fit straight line, over the device’s rated temperature
range.
LM61
www.national.com 3
