ISD14B20
Publication Release Date: October 9, 2007
- 11 - Revision 0
Part of
Message
PlayL
Sp+
Sp-
End of
Message
LED
Norm/Mode
T
Deb
T
ASet
Stop Start
Start
T
Settle2
T
AHold
T
AHold
T
ASet
T
EOM
T
Deb
T
Deb
• However, holding PlayL Low constantly will perform looping playback function, without power down,
from start address to end address.
Fig. 6: Looping playback function via PlayL
PlayL
Norm/Mode
T
Deb
T
ASet T
AHold
Sp+
Sp-
LED
T
EOM
T
EOM
5.1.4. Playback (Supersedes Record) Operation
• Playback takes precedence over the Recording operation.
• If
either PlayE or PlayL is activated during a recording cycle, the recording immediately ceases with
an EOM marker attached, and without power down, playback of the just-recorded message performs
accordingly. Then device powers down.
Fig. 7: An example of Playback supersedes Record
