ISD1800 SERIES
Publication Release Date: June 7, 2005
- 23 - Revision 0.3
ISD1800 PAD (X,Y) COORDINATES
(with respect to die center)
PAD # PAD Name Pin # X Axis (µm) Y Axis (µm)
1 AGC 13 -522.35 -1037.20
2
RECLED
28 -126.05 1038.70
3 VCCD 27 122.15 1038.70
4 XCLK 26 358.38 1038.70
5 FT 25 630.45 1018.90
6 VSSD 1 -368.95 1038.70
7 REC 2 -558.98 1038.70
8 PLAYE 3 -760.15 1038.70
9 PLAYL 4 -977.35 1038.70
10 SP+ 17 465.85 -1024.10
11 ROSC 19 1007.85 -1037.20
12 VCCA 18 772.85 -1037.20
13 VSSA 16 158.85 -1037.20
14 SP- 15 -148.15 -1024.10
15 MIC 10 -977.75 -1037.20
16 MIC REF 12 -741.75 -1037.20
NC 5
NC 6
NC 7
NC 8
NC 9
NC 11
NC 14
NC 20
NC 21
NC 22
NC 23
NC 24
